Made of a simple pin construction and link plate, steel leaf chains is identified by a number that refers to the lacing of the links and the pitch. The chains have particular features such as high tensile strength for each section area, that allows the design of smaller devices. There are A- and B- type chains in this series and both the AL6 and BL6 Series have the same pitch as RS60. Finally, these chains cannot be powered with sprockets.
In roller chains, the link plates have a higher fatigue resistance because of the compressive stress of press fits, yet the leaf chain just contains two outer press fit plates. On the leaf chain, the most acceptable tension is low and the tensile strength is high. Whenever handling leaf chains it is vital to check with the manufacturer's guidebook so as to guarantee the safety factor is outlined and use safety guards at all times. It is a great idea to carry out extreme caution and utilize extra safety measures in functions wherein the consequences of chain failure are severe.
Using more plates in the lacing results in the higher tensile strength. Because this does not improve the most permissible tension directly, the number of plates used may be restricted. The chains require frequent lubrication in view of the fact that the pins link directly on the plates, generating a very high bearing pressure. Using a SAE 30 or 40 machine oil is normally advised for the majority of applications. If the chain is cycled over 1000 times day after day or if the chain speed is over 30m for each minute, it would wear very quick, even with constant lubrication. So, in either of these situations the use of RS Roller Chains would be more suitable.
The AL-type of chains should only be utilized under particular conditions like for instance when wear is really not a huge issue, if there are no shock loads, the number of cycles does not go beyond 100 day by day. The BL-type would be better suited under different conditions.
The stress load in parts would become higher if a chain utilizing a lower safety factor is chosen. If the chain is likewise utilized amongst corrosive situations, it can easily fatigue and break very quick. Doing frequent maintenance is really vital when operating under these kinds of conditions.
